Fig. 5

Detection of hsp27 expression in sectioned embryos. Hsp27 mRNA is detected in trunk myotomes of embryos at 24 hpf (A) and in embryos at 48 hpf after heat shock (C) but not in embryos without heat shock obtained at 48 hpf (B) or 54 hpf (D). Hsp27 mRNA is not detected in tissues of the head 24 hpf (E), but is detected in the lens of unstressed embryos collected at 48 (F) and 54 (H) hpf. All tissues in the heads of 48 h hpf embryos show hsp27 expression after heat stress (G). Expression was also detected in the heart of 54 hpf embryos (arrow, H) and at the midbrain/hindbrain boundary of embryos at 48 hpf (arrow, I and J). Images are transverse sections (A–H) and coronal sections (I,J). Bar =50 μm (A–D,J) and 100 μm (E–I).

Expression Data

Gene:	hspb1
Fish:	WT
Condition:	heat shock
Anatomical Terms:	head heart midbrain hindbrain boundary myotome whole organism
Stage Range:	Prim-5 to Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 6(2), Mao, L., and Shelden, E.A., Developmentally regulated gene expression of the small heat shock protein Hsp27 in zebrafish embryos, 127-133, Copyright (2006) with permission from Elsevier. Full text @ Gene Expr. Patterns
