ZFIN Image: Hahn et al., 2020, Figure 2


Figure Caption

Figure 2 Early expression of <italic>ntrk2a</italic> is seen in the head and spinal cord using whole mount in situ hybridization at 16.5 hpf and 24 hpf.

Expression of ntrk2a is seen in the cranial ganglia (arrows) as well as in the RB neurons of the spinal cord (arrowheads) at (A and D) 16.5 hpf and (B, C, E and F) 24 hpf. The asterisk in E marks weak expression in the diencephalon that matches with previously published accounts. (A, B, C and F) Lateral view. (D and E) Dorsal view. All embryos are oriented with the head to the left. te, marks the telencephalon, mb, marks the midbrain, hb, marks the hindbrain, ov, marks the otic vesicle, chb, marks the caudal hindbrain and ye, marks the yolk extension. Data are representative of two rounds of in situ hybridization with at least 25 embryos per round.

Figure Data

Expression / Labeling details
