Fig 1

ID
ZDB-IMAGE-200225-1
Genes
Source
Figures for Belzunce et al., 2020
Figure Caption

Fig 1 Spatiotemporal analysis of <italic>atoh1a</italic> and <italic>atoh1b</italic> within the hindbrain.

A-E) Whole mount double in situ hybridization with atoh1a (green) and atoh1b (magenta) in wild type embryos from 14hpf to 42hpf. Dorsal views with anterior to the left. A’-E’) Reconstructed transverse views of dorsal views in (A-E) at the level indicated by the white arrow depicted in (A-E). Note that the expression of atoh1b is more lateral than atoh1a-cells. Dotted line corresponded to the neural tube contour. F-H) Whole mount double in situ hybridization with atoh1a (green) and atoh1b (magenta) on Tg[HuC:GFP] embryos from 24hpf to 42hpf, where HuC expression was displayed in white. Dotted line corresponded to the neural tube and the HuC-expression contours (only half of it). I-J) Embryos at 30hpf were double in situ hybridized with atoh1a (green) and atoh1b (magenta) and cell proliferation was assessed by anti-PH3 staining (white). Dorsal views with anterior to the left. I’-J’) Reconstructed transverse views of (I-J) at the level pointed by the white arrow in (I-J). Note atoh1a-cells underwent mitosis, whereas fewer atoh1b-cells did. Dotted line corresponded to the neural tube contour. K-K”) Tg[atoh1a:GFP] embryo after anti-PH3 (magenta) and DAPI (blue) staining. K’-K”) Reconstructed transverse views of the region framed in (K), which is a dorsal view with anterior to the left. This is an example of an apical atoh1a:GFP cell undergoing division (black asterisk) and lateral atoh1a:GFP cell that did not (white asterisk), with (K’) or without (K”) the red-PH3 staining. Note that atoh1a:GFP cell nuclei expressing PH3 are located in the apical region (black asterisks), whereas atoh1a:GFP cell nuclei negative for PH3 (most probably atoh1b-positive, white asterisk) are in the most lateral domain. L-L”) Tg[atoh1a:GFP] embryo incubated for 30min with BrdU (blue) and assayed for atoh1b in situ hybridization (magenta). Reconstructed transverse views with (L-L’) or without (L”) atoh1b-staining. White asterisks indicate atoh1b cells that did not incorporate BrdU. Dotted line corresponded to the neural tube contour. op, otic placode; ov, otic vesicle; r, rhombomere. Scale bars correspond to 50 μm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ PLoS One
