ZFIN ID: ZDB-IMAGE-180621-36
Figures for Wang et al., 2018

Genes:

Antibody:

Figure Caption/Comments:

Fig. 5

Lpar2b regulates Yap1 activity. (A,A) Whole-mount ISH detects the mRNA of yap1 in embryos at 34 hpf. (A) High-magnification of the pLLP in (A). (B,C) Epifluorescence images of control- or yap1 MO-injected Et(gata2:EGFP)mp189b embryos at 48 hpf. (D) Quantification of the NM number at 48 hpf and number of pLLP cells at 32 hpf in control- or yap1 MO-injected embryos. (E–F) Confocal images of the pLLP stained with DAPI (blue) and p-Yap1 (green) at 32 hpf. (G,H) ISH shows a decreased prox1a expression in the pLLP of Lpar2b morphants. The pLLP is outlined by dots. **p < 0.01 compared to control.

Figure Data:
