Fig. 7

ID
ZDB-IMAGE-140721-7
Genes
Source
Figures for Al Oustah et al., 2014
Figure Caption

Fig. 7

Partial inhibition of Hh signal transduction prior to each step of patterning progression is sufficient to prevent the correct temporal formation of the p3 and p* domains. Panels A-F and M-O show side views of whole embryos; all other panels show spinal cord transverse sections. (A-L) Expression of olig2 (A,C,E; brackets in G,J), nkx2.2a (B,D,F; arrow in H,K) and foxa2 (I,L) at 24 hpf in embryos incubated from 14 hpf in control solution (A,B,G-I) or in cyclopamine at 5 μM (C,D) or 1 μM (E,F,J-L). Note that 1 μM cyclopamine-treated embryos express olig2 (J) but not nkx2.2a (K) and foxa2 (L) in cells abutting the MFP (asterisks). (M-O) Detection of GFP at 72 hpf in Tg(olig2:EGFP) larvae incubated from 30 hpf in control solution (M) or in cyclopamine at 5 μM (N) and 1 μM (O). (P-U) Expression of olig2 (P,R,T) and nkx2.2a (Q,S,U) at 48 hpf in embryos incubated from 30 hpf in control solution (P,Q) or in cyclopamine at 5 μM (R,S) or 1 μM (T,U). Dashed lines indicate dorsal boundary of the nkx2.2a+ domain. Scale bars: 200 μm in A-F; 50 μm in M-O; 20 μm in G-L,P-U.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
