ZFIN ID: ZDB-IMAGE-110224-4
Figures for Dal-Pra et al., 2011

Genes:

Figure Caption/Comments:

Fig. 4 Gain of FoxA2 or FoxA3 function enlarges the axial mesoderm territory. Analysis of the axial mesoderm territory at midgastrula stage with two combinations of prechordal plate (red)/notochord (blue) markers, gsc/flh (A–D) and hgg1/shh (E–H). Embryos injected with foxA3 RNA present an enlargement of flh (B–D) and shh (F–H) expression domains compared to wild-type (A and E). When the axial mesoderm is massively enlarged, it splits in two distinct axes (arrow in D). Dorsal views, anterior up.

Figure Data:
Acknowledgments:
ZFIN wishes to thank the journal for permission to reproduce figures from this article. Please note that this material may be protected by copyright.
