Figure Caption
Fig. 4 Changes in Id2a levels alter the expression of neurogenic factors involved in retinal cell fate specification. (A-X) Lateral views of whole-mount in situ hybridizations detecting the initiation (A-L) and maintenance (M-X) of the indicated genes at the indicated time points in Id2a-MM, Id2a-MO and id2a-overexpressing zebrafish embryos. Pineal body expression of crx is indicated by arrows in J-L.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
