Fig. 1

ID
ZDB-IMAGE-080715-34
Genes
Source
Figures for Dutta et al., 2008
Figure Caption

Fig. 1 Prospective pituitary precursors express deltaA and notch1a after the 10-somite (14 h) stage. Wild-type embryos doubly labeled with mRNA probes for cathepsin L, 1b (ctsl1b), previously known as hatching gland gene 1 (hgg1; A–F, red) and pitx3 (A, B), deltaA (C, D), or notch1a (E, F). (A, C, E) At Bud stage, presumptive pituitary precursor cells express pitx3 (A, n = 25; dotted lines indicate approximate location according to Dutta et al., 2005). deltaA (C, n = 30) and notch1a (E, n = 30) are not expressed in pituitary precursors. At 10-somite stage (14 h), anterior cranial placode precursors (arrowheads) express pitx3 (B, n = 25), deltaA (D, n = 25), and notch1a (F, n = 25). (A, C, E) Dorsal views, anterior to the top (dotted lines indicate approximate location of pituitary precursor cells according to Dutta et al., 2005); (B, D, F) dorsal views of prospective head region, anterior to the top. Scale bar: 50 mμm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 319(2), Dutta, S., Dietrich, J.E., Westerfield, M., and Varga, Z.M., Notch signaling regulates endocrine cell specification in the zebrafish anterior pituitary, 248-257, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
