Fig. 5
|
Figure Caption
Fig. 5 Expression of hematopoietic markers in the trunk clusters and ventral tail of 4 dpf embryos. Whole-mount in situ hybridization to show mRNA expression (purple) of scl (A); runx1 (B); lmo2 (C); c-myb (D); gata1 (E); and βE1 globin (F). This expression supports the identification of the trunk clusters as hematopoietic. Compared with the other markers runx1 expression is expressed in much fewer cells in the ventral tail.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 307(2), Zhang, X.Y., and Rodaway, A.R., SCL-GFP transgenic zebrafish: In vivo imaging of blood and endothelial development and identification of the initial site of definitive hematopoiesis, 179-194, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
