FIGURE

Fig. 1

ID

ZDB-FIG-250218-44

Publication

Basol et al., 2024 - Loss of carbohydrate sulfotransferase 6 function leads to macular corneal dystrophy phenotypes and skeletal defects in zebrafish

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

The expression pattern of chst6 in zebrafish embryos. Whole mount in situ hybridization revealed expression of chst6 in the body of (A) 24 hpf, (B) 30 hpf, (C) 60 hpf, and (D) 72 hpf zebrafish. (E) Close-up image of the 72 hpf larval head shows strong expression in the brain and eye (arrow). The experiment was repeated three times and n = 15 for each stage. (F) Section of larvae post-in situ hybridization shows chst6 expression in the cornea (arrow); (G) larvae stained with negative control sense probe did not show any signal in the eye. (H) Representative images of 72 hpf larvae stained with chst6 sense probe (negative control). Scale bars: 100 μm.

Expression Data

Gene:	chst6
Fish:	AB
Anatomical Terms:	brain cornea eye head trunk ventral mandibular arch
Stage Range:	Prim-5 to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
