Figure 6

Differential expression of tooth marker genes in the trrap mutants. WISH analysis for dlx2b (a–d) and pitx2 (e–h) at 72 hpf. (a,c,e,g) Lateral views. (b,d,f,h) Ventral views. All pictures show the anterior aspect to the left. The expression of dlx2b (red arrow) and pitx2 (black arrow) in the developing teeth was weak in the mutants. After images were taken, genomic DNA was isolated from individual larvae, and genotyping was performed by genomic PCR. Scale bar, 200 μm.

Expression Data

Genes:	dlx2b pitx2
Fish:	WT trrap^uy45/uy45 trrap^uy45/+
Anatomical Term:	ceratobranchial 5 tooth
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	trrap^uy45/uy45
Observed In:	ceratobranchial 5 tooth
Stage:	Protruding-mouth

Phenotype Detail
