Figure 3

Comparison of expression patterns of tac1 mRNA in the hindbrain regions of male (I−L) and female (I’−L’) zebrafish. In the most-right panels (I”−L”), a schematic drawing of half of the brain section (left side) processed for tac1 staining indicating major brain structures at this level. There was no sex difference in expression of tac1 in the mesencephalic and rhombencephalic regions including the interpeduncular nucleus, dorsal tegmental nucleus, central gray, and trigeminal motor nucleus, while in the superior raphe, there was more tac1 expression in males as compared to females (J, J’). Scale bars: 200 µm. See glossary for abbreviation.

Expression Data

Gene:	tac1
Fish:	WT
Anatomical Terms:	female organism dorsal tegmental nucleus female organism griseum centrale female organism interpeduncular nucleus medulla oblongata female organism superior raphe nucleus female organism trigeminal motor nucleus male organism dorsal tegmental nucleus male organism griseum centrale male organism interpeduncular nucleus medulla oblongata male organism superior raphe nucleus male organism trigeminal motor nucleus
Stage:	Adult
