FIGURE

Fig. 2

ID

ZDB-FIG-190627-47

Publication

Otis et al., 2019 - Dietary cholesterol and apolipoprotein A-I are trafficked in endosomes and lysosomes in the live zebrafish intestine

Other Figures

All Figure Page

Back to All Figure Page

Fig. 2

Dietary TF-cholesterol localizes to the endosomal-lysosomal trafficking network in enterocytes. Representative images show that 3 h following the onset of feeding, dietary TF-cholesterol colocalizes to mCherry-Rab5c (early endosomes) (A), mCherry-Rab11a (recycling endosomes) (B), and mCherry-Rab7 (late endosomes) (C). n = 3, with 3–9 fish per n; all fish 6-dpf. TF-cholesterol colocalizes with BODIPY TR ceramide, which marks the trans-Golgi network, in enterocytes after 4 h of feeding (D). n = 3, with 3–6 fish per n. Arrows indicate colocalization; dpf, days postfertilization; L, intestinal lumen; N, nucleus; TF-cholesterol, TopFluor-cholesterol.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Am. J. Physiol. Gastrointest. Liver Physiol.
