Fig. S1

Morphology of paralog group 1 hox mutants.

Embryos were imaged consecutively at 22hpf (A–D), 48hpf (E-H) and 72hpf (I–L) to examine gross morphological defects. Hoxb1a^−/− mutants (B, F, J) do not have any major morphological defects as compared to wildtype embryos. (A, E, I) Hoxb1b^−/− mutants have a small otic vesicle at 22hpf (C) which does not persist at later stages (G, K). Hoxb1a^−/− hoxb1b^−/− mutants have a small otic vesicle at 22hpf (D) and develop cardiac edema at later stages (H, L). All embryos have been genotyped for hoxb1a^sa1191 and hoxb1b^ua1006. All embryos are lateral views, anterior to the left. Hpf, hours post fertilization.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	hoxb1b^{ua1006/ua1006} hoxb1a^{sa1191/sa1191}; hoxb1b^{ua1006/ua1006}
Observed In:	otic vesicle pericardium
Stage Range:	26+ somites to Protruding-mouth
