Fig. 7

G?1 signaling regulates F-actin dynamics in neutrophils. Snapshots from confocal time-lapse imaging (Supplementary Movies 7 and 8) of migrating neutrophils expressing Lifeact-GFP in control and gnb1a/b MO1-injected embryos (3 cells in 3 embryos for each group) following wounding. (A-F) Lifeact-GFP. (A?-F?) DsRed. (A??-F??) Ratiometric images of Lifeact-GFP/DsRed. Yellow asterisks: side nearest wound; white arrowheads: sites of Lifeact-GFP enrichment in leading and trailing fronts of neutrophils.

Expression Data

Gene:	GFP
Fish:	e114Tg e114Tg + MO1-gnb1a + MO2-gnb1b + MO4-tp53
Condition:	amputation: caudal fin
Knockdown Reagents:	MO1-gnb1a MO2-gnb1b MO4-tp53
Anatomical Term:	neutrophil
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	e114Tg + MO1-gnb1a + MO2-gnb1b + MO4-tp53
Condition:	amputation: caudal fin
Knockdown Reagents:	MO1-gnb1a MO2-gnb1b MO4-tp53
Observed In:	neutrophil
Stage:	Protruding-mouth

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 428(1), Ke, W., Ye, D., Mersch, K., Xu, H., Chen, S., Lin, F., G?1 is required for neutrophil migration in zebrafish, 135-147, Copyright (2017) with permission from Elsevier. Full text @ Dev. Biol.
