FIGURE

Fig. 5

ID

ZDB-FIG-160608-9

Publication

Tokumasu et al., 2016 - ADAM12-deficient zebrafish exhibit retardation in body growth at the juvenile stage without developmental defects

Other Figures

All Figure Page

Back to All Figure Page

Fig. 5

Identification of adam12-EGFP positive cells. (A, B) Confocal micrographs of the ICM region of double transgenic Tg[adam12:EGFP/gata1a:mRFP] or Tg[adam12:EGFP/fli1a:myr-mCherry] embryos. (A) Primitive erythroblasts expressing RFP at 24 hpf. (B) Endothelial cells expressing mCherry at 30-hpf. Nuclei are labeled with DAPI. DA, dorsal aorta; PCV, posterior cardinal vein. Scale bar: 20 µm. (C) MYH expression as determined by immunocytochemistry. MyC, myocardium; EnC, endocardium. Scale bar: 200 µm.

Expression Data

Genes:	EGFP mCherry mRFP
Antibody:	Ab1-smyhc
Fish:	ko110Tg ko05Tg; ko110Tg ko110Tg; ncv1Tg
Anatomical Terms:	endocardium endothelial cell erythroblast intermediate cell mass of mesoderm myocardium
Stage Range:	Prim-5 to Prim-15

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
