Fig. 8

Figure 8. Expression of esco2 mRNA in WT and short fin (sof ^b123) fins by whole-mount in situ hybridization. WT and sof ^b123 fins were amputated at 50% level and allowed to regenerate for 5 days. At 5 dpa, the fins were harvested. At least six to eight fins were used per trial and 3 independent trials were performed. Left: Whole-mount in situ hybridization (ISH) on WT-5 dpa regenerating fins showing esco2 expression. Right: Whole-mount ISH on sof ^b123 -5 dpa regenerating fins shows similar expression levels of esco2. The brackets represent the zone of esco2 expression. Scale bar = 50 µm.

Expression Data

Gene:	esco2
Fish:	C32 gja1b^b123 (AB)
Condition:	amputation: fin
Anatomical Term:	regenerating fin
Stage:	Adult
