Fig. 1

Time course in situ hybridization of esco2 in whole-mount regenerating fins. A: esco2 expression in 1 day postamputated (dpa) regenerating fins was largely not detectable. B,C: esco2 expression in 3 dpa regenerating fins was strongly detected at the distal end (B) and began to gradually decline in 5 dpa regenerating fins (C). D: Expression of esco2 was reduced in regenerating fins by 8 dpa. The amputation plane is indicated by a solid line except in 8 dpa regenerating fin (D), where it is out of the field of view. Scale bar = 50 µm.

Expression Data

Gene:	esco2
Fish:	C32
Condition:	amputation: fin
Anatomical Term:	regenerating fin
Stage:	Adult

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	C32
Condition:	amputation: fin
Observed In:	regenerating fin
Stage:	Adult

Phenotype Detail
