Fig. S1

NF-_KB factors during heart regeneration. (A–H) In situ hybridization for NF-_KB transcription factors on sections from ventricles of cmlc2:CreER; βact2:RS-DTA animals treated with vehicle (A–D) or tamoxifen (E–H) to diffusely ablate cardiomyocytes. nfkb1 was the only gene from this group to show a detectable signal in cardiomyocytes. (I–K) Staining of uninjured adult mouse hearts for NF-_KB1 and Tnnt, indicating that NF-_KB1 is present in murine cardiomyocytes (arrowheads). We did not detect an obvious difference in NF-_KB1⁺ cardiomyocytes in compact versus trabecular muscle. (Scale bar: 100 µm.)
