Fig. 5

Spatial expression pattern of brinp2 during zebrafish development. brinp2 is ubiquitously expressed at 10?18 hpf (A, B). At 24 hpf, brinp2 is detected specifically in the developing brain (b) of younger embryos (C,D). Staining is concentrated at the myosepta (Ci), cross section of 24 hpf embryos also reveal that brinp2 is expressed in the muscle (Di). At 48 hpf, expression is broadly detected in the brain and in the fin buds (fb) (E, Ei). In older embryos (72 hpf) brinp2 is highly and preferentially expressed in the brain and fins (F, Fi). Lateral (C, E, F) and dorsal (D, Ei, Fi) views are shown.

Expression Data

Gene:	brinp2
Fish:	WT
Anatomical Terms:	brain fin bud muscle myoseptum whole organism
Stage Range:	Bud to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 18(1-2), Giousoh, A., Vaz, R., Bryson-Richardson, R.J., Whisstock, J.C., Verkade, H., Bird, P.I., Bone morphogenetic protein/retinoic acid inducible neural-specific protein (brinp) expression during Danio rerio development, 37-43, Copyright (2015) with permission from Elsevier. Full text @ Gene Expr. Patterns
