Fig. S1

Dbx1b is expressed in the dorsal diencephalon. Lateral and dorsal views of a 28 hpf wildtype embryo. (A and B) In situ hybridization for dbx1a (blue) revealed several expression domains, including the olfactory bulb (Ob), prethalamus (pT), thalamus (Th), and midbrain (Mb) throughout the brain, but no expression in the dorsal diencephalon (arrow heads). (C and D) dbx1b transcript (blue) was expressed in a similar pattern but with greatly reduced expression in thalamus and robust expression in the dorsal diencephalon and olfactory bulb. otx5 (red) marks the pineal complex (P), a component of the dorsal diencephalon. Scale bars are 10 μm.

Expression Data

Genes:	dbx1a dbx1b otx5
Fish:	AB
Anatomical Terms:	dorsal habenular nucleus midbrain olfactory placode pineal complex thalamus ventral thalamus
Stage:	Prim-5
