Fig. 2
- ID
- ZDB-FIG-150304-21
- Publication
- Tsuruwaka et al., 2015 - Loss of wwox expression in zebrafish embryos causes edema and alters Ca(2+) dynamics
- Other Figures
- All Figure Page
- Back to All Figure Page
Knockdown of wwox induced pericardial edema and reduced eye formation in embryos during the long-pec stage at 48 h post fertilization. Arrows indicate edema; (A) Upper, A bright-field image of a (i) wild-type embryo; (ii) wwox negative-control MO-injected embryo; and (iii) wwox MO-injected embryo; Lower, fluorescence image of the upper panel. (B) A wwox siRNA-injected embryo. (C) A wwox rescued MO-injected embryo (upper, bright-field image; lower, fluorescence image). (D) A wwox rescued siRNA-injected embryo. (E) Quantification of body lengths and eye sizes of long-pec embryos; 30 embryos were examined in three independent experiments and data are expressed as means ± SEM (∗∗p < 0.01); WT, wildtype; Scale bars, 250 µm. |
Fish: | |
---|---|
Knockdown Reagent: | |
Observed In: | |
Stage: | Long-pec |
