Fig. S2

notch3fh332 mutants have reduced Notch signaling activity. (A,B) Wild-type and notch3fh332 mutant larvae showing trunk curvature of the mutant at 3 dpf. (C-F) notch3fh332; Tg(Tp1bglob:hmgb1-mCherry) (Tp1:mCherry) mutant larvae showed reduced mCherry expression compared to wild-type siblings at 3 dpf and 5 dpf. (G,H) Whole-mount ISH revealed similar her4.1 expression in notch3fh332 mutant and wild-type sibling. (I-L) notch3fh332 mutants showed reduced hey1 and her9 expression compared to wild-type siblings.

Expression Data

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Observed In:
Stage: Protruding-mouth

Phenotype Detail
