FIGURE

Fig. 7

ID

ZDB-FIG-140303-13

Publication

Thisse et al., 1993 - Structure of the zebrafish snail1 gene and its expression in wild-type, spadetail and no tail mutant embryos

Other Figures

All Figure Page

Back to All Figure Page

Fig. 7

Expression pattern of snail1 in no tail embryos. (A,B) Posterior views of 5-somite stage; (C,D) lateral views of 12-somite stage; (A,C) wild-type embryos; (B,D) no tail embryos. Compared to a wild-type embryo (A), note the reduction of snail1 signal in no tail, especially in the tail bud, even though this no tail embryo was stained for 6 hours to be able to see a clear signal, and the wild-type control was stained for just 2 hours. The axial mesoderm territory is broader in no tail embryos. In contrast to wild type (C), an overstained no tail embryo shows an absence of snail1 staining in the tail. Since the mutant embryo was stained for a long time, background staining started to become visible.

Expression Data

Gene:	snai1a
Fish:	WT tbxta^{unspecified/unspecified}
Anatomical Terms:	paraxial mesoderm somite tail bud
Stage Range:	5-9 somites to 10-13 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
