ZFIN ID: ZDB-FIG-130820-592
Frohnhöfer et al., 2013 - Iridophores and their interactions with other chromatophores are required for stripe formation in zebrafish. Development (Cambridge, England)   140(14):2997-3007 Full text @ Development
ADDITIONAL FIGURES
PHENOTYPE:
Fish:
Observed In:
Stage: Adult

Fig. 2 Details of adult phenotypes in iridophore mutants. Images of the anterior trunk of fixed animals photographed under white light. L-iridophores (black arrows) and dense S-iridophores (white arrows) reflect maximally at different angles of light and therefore shine up in different anteroposterior regions. Insets in A-C demarcate the magnified views in A′-C′ that were taken under UV light to avoid reflections from iridophores and to highlight xanthophores. Under this illumination, L-iridophores are visible as bundles of greyish vertically oriented fibres (black arrows). (A,A′) Wild-type fish. (B,B′) rse mutant fish. An illumination was chosen to avoid reflection of L-iridophores, whereas S-iridophores are visible (white arrow). L-iridophores, which are largely restricted to melanophore regions in wild type (A,A′, black arrows), expand into interstripe regions in rse mutants (B,B′). The light appearance in stripe 1D in B′ is due to the absence of L-iridophores. (C,C′) shd mutant fish. Ventrally, some of the melanophore patches (grey arrows) appear to be located between 1V and 2V. The light area in X0 in C′ is probably due to reflective properties of musculature.

Gene Expression Details No data available
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
ednrbatlf802/tlf802 standard conditions Adult iridophore differentiation decreased occurrence, abnormal
Adult trunk dermis has fewer parts of type iridophore, abnormal
Adult trunk melanophore stripe has fewer parts of type melanocyte, abnormal
ltkj9s1/j9s1 standard conditions Adult iridophore differentiation decreased occurrence, abnormal
Adult trunk dermis lacks all parts of type iridophore, abnormal
Adult trunk melanocyte mislocalised, abnormal
Adult trunk melanophore stripe has fewer parts of type melanocyte, abnormal
Adult trunk melanophore stripe malformed, abnormal
