Fig. 4

Csrnp1a reduction does not affect the hemato-angiogenic mesoderm.

In situ hybridization indicating the expression of the hemangioblast marker, tal1/scl at 8 somites (A to D) (A, B anterior view; C, D posterior view). Control and morphant 32 hpf transgenic zebrafish embryos expressing GFP under the promoter of the endothelial marker fli1a (Tg(fli1a:EGFP)^y1)(E, F) (lateral view, anterior to the left). We did not observe difference in either marker in 100% of the injected embryos (n = 53).

Expression Data

Gene:	tal1
Fish:	AB/TU AB/TU + MO1-csrnp1a
Knockdown Reagent:	MO1-csrnp1a
Anatomical Terms:	anterior lateral plate mesoderm posterior lateral plate mesoderm
Stage:	5-9 somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	y1Tg + MO1-csrnp1a
Knockdown Reagent:	MO1-csrnp1a
Observed In:	blood vessel blood vessel development
Stage:	Prim-15

Phenotype Detail
