FIGURE

Fig. S3

ID

ZDB-FIG-121011-29

Publication

Kizil et al., 2012 - The chemokine receptor cxcr5 regulates the regenerative neurogenesis response in the adult zebrafish brain

Other Figures

(all 11)

All Figure Page

Back to All Figure Page

Fig. S3

cxcr5 is not expressed in L-Plastin-positive cells in the adult zebrafish telencephalon. (A) cxcr5 in situ hybridization coupled to immunohistochemistry for L-Plastin (red, marking macrophages and microglia) and her4.1:green fluorescent protein (GFP) (green, marking the radial glial cells) in the unlesioned telencephalons. White asterisks indicate the L-Plastin cells. (A1-A3) Individual channels for L-Plastin, her4.1:GFP and cxcr5, respectively. (B) cxcr5 in situ hybridization coupled to immunohistochemistry for L-Plastin and her4.1:GFP in the lesioned telencephalons (dorsolateral region). White asterisks indicate the L-Plastin cells. (B1-B3) Individual channels for L-Plastin, her4.1:GFP and cxcr5, respectively. (C) cxcr5 in situ hybridization coupled to immunohistochemistry for L-Plastin and her4.1:GFP in the lesioned telencephalons (dorsomedial region). White asterisks indicate the L-Plastin cells. (C1-C3) Individual channels for L-Plastin, her4.1:GFP and cxcr5, respectively.

Expression Data

Genes:	cxcr5 EGFP lcp1
Antibody:	Ab2-lcp1
Fish:	y83Tg
Condition:	physical alteration: anatomical structure
Anatomical Terms:	telencephalon macrophage telencephalon microglial cell telencephalon radial glial cell telencephalon ventricular zone
Stage:	Adult

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
