Fig. 1

Tg(isl1:GFP)^rw0 reporter expression reveals a facial motor neuron migration defect in olig2 MO-injected embryos as compared to wild-type and control MO-injected embryos. Panels are z-stack images showing dorsal views of whole embryos with anterior to the left. A–C: Wild-type embryos. D–F:olig2 MO-injected embryos. G–I: Control MO-injected embryos. Arrows indicate posteriorly migrated facial motor neurons. Bar indicates facial motor neurons along their caudal migration. Cranial motor neurons are labeled “n.” Otic vesicles are outlined. Scale bar = 30 μm.

Expression Data

Gene:	GFP
Fish:	rw0Tg rw0Tg + MO4-olig2
Knockdown Reagent:	MO4-olig2
Anatomical Terms:	facial nerve motor nucleus trigeminal motor nucleus vagal lobe
Stage Range:	Prim-5 to Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	rw0Tg + MO4-olig2
Knockdown Reagent:	MO4-olig2
Observed In:	facial nerve motor nucleus motor neuron neuron migration
Stage Range:	Prim-5 to Long-pec

Phenotype Detail
