FIGURE

Fig. 1

ID

ZDB-FIG-110817-11

Publication

Neumann et al., 2011 - Mutation in the type IB bone morphogenetic protein receptor alk6b impairs germ-cell differentiation and causes germ-cell tumors in zebrafish

Other Figures

(all 7)

All Figure Page

Back to All Figure Page

Fig. 1

The tgct mutants develop GCTs because of impaired germ-cell differentiation. Compared with adult wild-type males (A and C) (arrowhead: normal testis), adult tgct males display marked testicular enlargement (B and D) (arrow: testicular tumor). Wild-type testis (E) exhibits normal spermatogenesis (arrowhead: spermatogonia; arrow: spermatozoa). The tgct mutant testis (F) accumulates primitive germ cells. Although wild-type ovary (G) shows all stages of oocyte maturation up to mature stage IV oocytes, oocyte maturation is impaired in tgct homozygous females (H). [Scale bars: 100 μm (E and F); 50 μm (G and H).]

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	bmpr1bb^sw40/sw40
Observed In:	female organism germ cell development oocyte maturation oocyte stage IV primordial germ cell testis testis germ cell tumor (all 7)
Stage:	Adult

Phenotype Detail
