Fig. 7

The zfprrx1b2CNE(cFos):EGFP transgenic lines. A?D: The zfprrx1b2CNE(cFos):EGFP reporter line#11. E?H: The zfprrx1b2CNE(cFos):EGFP line#13. For all the embryos, dorsal views are shown with anterior to the right, whereas lateral views with anterior to the right are shown for the fin bud details. The asterisks mark the unlabelled fin ectoderm and the arrows the scapulocoracoid. ed, endoskeletal disc; pff, pectoral fin fold.

Expression Data

Gene:	EGFP
Fish:	ib8Tg ib9Tg
Anatomical Terms:	mesenchyme pectoral fin pectoral fin bud pectoral fin cartilage pectoral fin fold mesenchyme scapulocoracoid
Stage Range:	Prim-5 to Protruding-mouth

Expression Detail

Gene	Fish	Conditions	Stage	Qualifier	Anatomy	Assay
EGFP	ib8Tg	standard conditions	Prim-5		pectoral fin bud	IFL
EGFP	ib8Tg	standard conditions	Prim-15		mesenchyme pectoral fin	IFL
EGFP	ib8Tg	standard conditions	Long-pec		mesenchyme pectoral fin	IFL
EGFP	ib8Tg	standard conditions	Protruding-mouth	Not Detected	pectoral fin	IFL
EGFP	ib9Tg	standard conditions	Prim-5		pectoral fin bud	IFL
EGFP	ib9Tg	standard conditions	Prim-15		mesenchyme pectoral fin	IFL
EGFP	ib9Tg	standard conditions	Long-pec		mesenchyme pectoral fin	IFL
EGFP	ib9Tg	standard conditions	Protruding-mouth		pectoral fin cartilage	IFL
EGFP	ib9Tg	standard conditions	Protruding-mouth		pectoral fin fold mesenchyme	IFL
EGFP	ib9Tg	standard conditions	Protruding-mouth		scapulocoracoid	IFL
