Fig. 2

Whole-mount in situ hybridization analysis of the zebrafish usp39 expression pattern.

Embryonic ages are shown in the lower right corner, lateral view. A–C: Expression of usp39 in wt is found in the brain and eye region. (A) Inset shows additional usp39 expression in the intermediate cell mass, site of embryonic zebrafish hematopoiesis. (B) usp39 expression is highest at 36 hpf. (C) usp39 expression declines by 42 hpf. (D) The expression pattern of usp39 in usp39 mutants is lower in all stages; expression at 42 hpf is depicted.

Expression Data

Gene:	usp39
Fish:	WT usp39^zf232/zf232
Anatomical Terms:	brain eye immature eye intermediate cell mass of mesoderm
Stage Range:	20-25 somites to High-pec
