ZFIN ID: ZDB-FIG-100628-13
Reynolds et al., 2010 - VANGL1 rare variants associated with neural tube defects affect convergent extension in zebrafish. Mechanisms of Development   127(7-8):385-392 Full text @ Mech. Dev.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Knockdown Reagent:
Anatomical Term:
Stage Range: 5-9 somites to 14-19 somites
PHENOTYPE:
Fish:
Knockdown Reagent:
Observed In:
Stage: Long-pec

Fig. 1 Activity of mouse Looptail VANGL1 mutant RNAs in zebrafish lacking tri. Panels A–E show lateral views of zebrafish at 2 days post fertilization. In Panel A, an uninjected wild-type fish is shown. In Panel B, a fish injected with tri-MO alone show a marked shortening of the trunk. In Panel C, VANGL1 RNA partially rescued the trunk phenotype induced by co-injection of tri-MO. Co-injection of VANGL1D259E (Panel D) or VANGL1S467N (Panel E) with tri-MO did not rescue the reduced body length phenotype induced by tri-MO.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
myod1 WT control 5-9 somites to 14-19 somites somite ISH
WT + MO1-vangl2 standard conditions 5-9 somites to 14-19 somites somite ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO1-vangl2 standard conditions Long-pec trunk decreased length, abnormal
Long-pec whole organism anterior-posterior axis decreased length, abnormal
