Fig. 7

Cell degeneration phenotype of GAK morphant embryos during development. (A, E) Lateral and (B, F) dorsal views of (A, B) uninjected and (E, F) GAK morphant embryos at 14-somite stage. Visible degeneration in the eyes (E) and the forebrain regions (F) of GAK morphants is indicated by white arrowheads. (C, G) Lateral and (D, H) dorsal views of (C, D) uninjected and (G, H) GAK morphant embryos at 24 hpf. At this stage, the increased cell degeneration within the brain (arrowheads) and thinner yolk extension in GAK morphants is apparent. (I-L) Lateral views of (I, J) uninjected and (K, L) GAK morphant embryos at 36 hpf. In all the lateral views, anterior is to the left and dorsal is up. ey, eye; Hb, hindbrain; nt, neural tube; no, notochord; ov, otic vesicles; ye, yolk extension. Scale Bar, 100 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-gak
Knockdown Reagent:	MO1-gak
Observed In:	blood circulation brain brain cell extension eye cell hindbrain tectal ventricle
Stage Range:	14-19 somites to Prim-25

Phenotype Detail
