ZFIN Image: Bai et al., 2010, Fig. 7


Figure Caption

Fig. 7 Cell degeneration phenotype of GAK morphant embryos during development. (A, E) Lateral and (B, F) dorsal views of (A, B) uninjected and (E, F) GAK morphant embryos at 14-somite stage. Visible degeneration in the eyes (E) and the forebrain regions (F) of GAK morphants is indicated by white arrowheads. (C, G) Lateral and (D, H) dorsal views of (C, D) uninjected and (G, H) GAK morphant embryos at 24 hpf. At this stage, the increased cell degeneration within the brain (arrowheads) and thinner yolk extension in GAK morphants is apparent. (I-L) Lateral views of (I, J) uninjected and (K, L) GAK morphant embryos at 36 hpf. In all the lateral views, anterior is to the left and dorsal is up. ey, eye; Hb, hindbrain; nt, neural tube; no, notochord; ov, otic vesicles; ye, yolk extension. Scale Bar, 100 μm.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ BMC Dev. Biol.
