Fig. 3

EphA4 and EfnB2a mediate hindbrain boundary sharpening during the neural keel stage. Whole mount (A) and 10 μm plastic sections (B?G) of RNA in situ hybridizations with a krox20/egr2b riboprobe. Anterior is to the left, dorsal or lateral views are indicated. Left panels show uninjected control embryos; right panels show stage-matched EphA4; EfnB2a double MO embryos. (A) Neural plate stage (N = 20); (B) neural plate to neural keel transition; (C,D) successive neural keel stages; (E,F) successive neural rod stages; (G) neural tube stage. Nc: r5-derived neural crest. Representative sections for each timepoint were chosen from at least 8 identically treated embryos. Scale bar: 50 μm.

Expression Data

Gene:	egr2b
Fish:	WT WT + MO1-epha4a + MO2-efnb2a
Knockdown Reagents:	MO1-epha4a MO2-efnb2a
Anatomical Terms:	neural crest presumptive rhombomere 3 presumptive rhombomere 5 rhombomere 3 rhombomere 5
Stage Range:	5-9 somites to 14-19 somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-epha4a + MO2-efnb2a
Knockdown Reagents:	MO1-epha4a MO2-efnb2a
Observed In:	rhombomere 3 rhombomere 5 rhombomere boundary formation
Stage Range:	5-9 somites to 14-19 somites

Phenotype Detail
