FIGURE

Fig. 1

ID

ZDB-FIG-080904-34

Publication

Kimura et al., 2008 - V2a and V2b neurons are generated by the final divisions of pair-producing progenitors in the zebrafish spinal cord

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

vsx1 mRNA and vsx1:GFP expression in spinal cord. (A,B) vsx1 mRNA expression in 22 hpf embryos. Broken lines outline the boundary of the spinal cord. (A) Cross-section. (B) Lateral view of a whole mount. (C) Tg[vsx1:GFP] fish at 2.5 dpf. (D,E) Expression of GFP and Vsx1 in Tg[vsx1:GFP] embryos at (D) 17 hpf and (E) 19 hpf. Arrows indicate pairs of labeled cells. Arrowheads indicate single labeled cells.

Expression Data

Genes:	GFP vsx1
Fish:	WT nns5Tg
Anatomical Terms:	brain eye spinal cord spinal cord interneuron
Stage Range:	14-19 somites to Pec-fin

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
