ZFIN ID: ZDB-FIG-080515-1
Willot et al., 2002 - Cooperative action of ADMP- and BMP-mediated pathways in regulating cell fates in the zebrafish gastrula. Developmental Biology   241(1):59-78 Full text @ Dev. Biol.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Anatomical Term:
Stage: Shield

Fig. 10 admp induction at the blastoderm ventral margin. (A–E) In situ hybridization with an admp probe at the shield stage. (A–D) Embryos were injected at the 16-cell stage into one marginal blastomere with nls-gfp RNA as a lineage tracer, sorted according to the position of the injection relative to the dorsal side. Ventrally injected embryos were processed for in situ hybridization (animal pole views, ventral to the top). (A) Uninjected embryo. (B) Ventral injection of boz RNA (2 pg). (C) Ventral injection of Δ alk6 RNA (25 pg). (D) Ventral injection of tar* RNA (2 pg). Arrows indicate the induced admp expression domain. (E) Progeny of an oep-/- X oep-/+ cross. Fifty percent of the embryos (MZoep) had a reduced admp expression domain compared with wild-type siblings (wt).

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
admp WT standard conditions Shield shield ISH
tdgf1tz257/tz257 standard conditions Shield shield ISH
Antibody Labeling Details No data available
Phenotype Details No data available
Acknowledgments:
ZFIN wishes to thank the journal Developmental Biology for permission to reproduce figures from this article. Please note that this material may be protected by copyright.

Reprinted from Developmental Biology, 241(1), Willot, V., Mathieu, J., Lu, Y., Schmid, B., Sidi, S., Yan, Y.-L., Postlethwait, J.H., Mullins, M., Rosa, F., and Peyriéras, N., Cooperative action of ADMP- and BMP-mediated pathways in regulating cell fates in the zebrafish gastrula, 59-78, Copyright (2002) with permission from Elsevier. Full text @ Dev. Biol.
