FIGURE

Fig. 8

ID

ZDB-FIG-071029-6

Publication

Kallivretaki et al., 2007 - The zebrafish, brain-specific, aromatase cyp19a2 is neither expressed nor distributed in a sexually dimorphic manner during sexual differentiation

Other Figures

(all 8)

All Figure Page

Back to All Figure Page

Fig. 8

Double immunofluorescence for CYP19A2 and BLBP. A-C: Most of the cells that surround the telencephalic ventricle (TelV) at the level of the dorsal nucleus (Vd) of the ventral telencephalic area that are positive for CYP19A2 are also positive for BLBP, with some exceptions (arrows). D-F: The majority of the cells in the posterior tuberal nucleus (PTN) and at least some levels of the ventral zone of the periventricular hypothalamus (Hv) are double positive. G-I: The part of the Hv that comes in contact with the pituitary is not double labeled (arrow in I). Scale bar = 10 μm.

Expression Data

Gene:	cyp19a1b
Fish:	WIK
Anatomical Terms:	caudal tuberal nucleus telencephalon ventral hypothalamic zone
Stage Range:	Days 30-44 to Days 45-89

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
