Fig. 3

Keratinocyte aggregation and shedding caused by the loss of Hai1a is further enhanced by the concomitant loss of its paralog, Hai1b. All panels show embryos at 24 hpf; wild-type siblings (WT; A-C), hai1a mutants (D-F), hai1a morphants (G-I), hai1b morphants (J-L) and hai1a mutants injected with hai1b MOs (M-O). Shown are lateral views of live embryos using Nomarski optics at low power (A,D,G,J,M) to assess overall embryo morphology, and at higher magnification (B,E,H,K,N) to assess epidermal defects in the trunk/tail regions, and lateral views of embryos after immunofluorescent detection of the basal epidermal marker protein p63 (C,F,I,L,O; merged stacks of confocal images).

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	spint1a^{hi2217Tg/hi2217Tg} WT + MO1-spint1a WT + MO1-spint1a + MO1-spint1b
Knockdown Reagents:	MO1-spint1a MO1-spint1b
Observed In:	chorion epidermal basal stratum keratinocyte epidermis development keratinocyte
Stage:	Prim-5
