FIGURE

Fig. 8

ID
ZDB-FIG-071008-18
Publication
Carney et al., 2007 - Inactivation of serine protease Matriptase1a by its inhibitor Hai1 is required for epithelial integrity of the zebrafish epidermis
Other Figures
All Figure Page
Back to All Figure Page
Fig. 8

Inactivation of Met fails to rescue epithelial defects in hai1a mutants. (A-C) Lateral Nomarski images of a wild-type sibling (WT; A), hai1a mutant (B) and met (cmet) MO-injected hai1a mutant (C) at 48 hpf, revealing the presence of epidermal aggregates both in injected (C) and un-injected (B) mutants. (D-F) Dorsal views of the trunk region of embryos shown in A-C, with the pectoral fin muscle labeled for myoD transcripts. The pectoral fin muscle is absent from the met morphant (F), compared with un-injected siblings (D,E), demonstrating that the MO is functional. Notice the presence of normal pectoral fin muscle in the hai1a mutant (E), indicating that Hai1a is dispensable for the Hgf- and Met-dependent migration of fin muscle precursor cells (Haines et al., 2004).

Expression Data
Gene:
Fish:
Anatomical Term:
Stage: Long-pec

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Observed In:
Stage: Long-pec

Phenotype Detail
