Fig. S4

Tcf3 reduction affects midbrain size. (A-C) Uninjected control embryos showing normal zic2aD5:gfp (A), zic2a (B) and wnt3a (C) expression at 18-somites. (D-O) Embryos injected with tcf3 MOs and assayed for zic2aD5:gfp (G,J,M), zic2a (H,K,N), or wnt3a (I,L,O) expression at 18-somites. Knockdown of Tcf3 resulted in expanded expression of all markers in the midbrain at low MO concentrations. This is most likely due to the previously documented overall midbrain expansion (D-I). At higher MO concentrations, zic2aD5:gfp and zic2a were reduced in midbrain (J,M,K,N), whereas wnt3a expression remained strong (L,O). Embryos are shown in lateral view, anterior to the left. Arrowheads mark anterior and posterior limits of the midbrain.

Expression Data

Genes:	wnt3a zic2a
Fish:	WT WT + MO1-tcf7l1b + MO2-tcf7l1a
Knockdown Reagents:	MO1-tcf7l1b MO2-tcf7l1a
Anatomical Terms:	diencephalon hindbrain midbrain neural tube optic stalk telencephalon
Stage:	14-19 somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-tcf7l1b + MO2-tcf7l1a
Knockdown Reagents:	MO1-tcf7l1b MO2-tcf7l1a
Observed In:	midbrain
Stage:	14-19 somites

Phenotype Detail
