Fig. 5
Late embryonic and larval expression (1–4 dpf) of the zebrafish ror genes. A–C, G–I, M–O, S–U are dorsal views. D–F, J–L, P–R, V–X are lateral views. All embryos oriented anterior to left. dc, diencephalon; ey, eye; gu, gut; he, heart; le, lens; li, liver; pg, pineal gland; px, pharynx; re, retina; so, somites. Scale bars: 200 μm. |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Anatomical Terms: | |
| Stage Range: | Prim-5 to Day 4 |
Expression Detail
Antibody Labeling
Phenotype Data
Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Gene expression patterns : GEP, 7(5), Flores, M.V., Hall, C., Jury, A., Crosier, K., and Crosier, P., The zebrafish retinoid-related orphan receptor (ror) gene family, 535-543, Copyright (2007) with permission from Elsevier. Full text @ Gene Expr. Patterns
