Fig. 6

The posterior lateral line system in a 5-mis MO-injected embryo (A) and embryos injected with RcadMphA (B-D) as revealed by anti-acetylated tubulin immunostaining. A-C: Lateral views of whole embryos (50 hpf, anterior to the left and dorsal up) of the same magnification. D: A higher magnification of lateral view of the anterior half of an older cdh4 morphant (72 hpf, anterior to the left and dorsal up). In all panels, arrows point to the lateral line nerve, while the arrowhead indicates the terminus of the lateral line nerve.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-cdh4
Knockdown Reagent:	MO1-cdh4
Observed In:	posterior lateral line nerve
Stage Range:	Long-pec to Protruding-mouth

Phenotype Detail
