FIGURE

Fig. 5

ID

ZDB-FIG-070308-4

Publication

Te Velthuis et al., 2007 - Gene expression patterns of the ALP family during zebrafish development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 5

Expression pattern of the zebrafish mystique gene by in situ hybridization. mystique expression in eight developmental stages of zebrafish embryogenesis is shown. mystique expression was observed in the CNS, in branchial arches (ba) and the lens (ls). In figure G a frontal view of a 48 h old embryos is shown to illustrate the mystique expression in the intermandibularis posterior (imp) and medial rectus (mr). Further expression was found in the arterial arches (aa), hindbrain (hb), intestine (in), liver (lv), medial rectus (mr), myotomes (myt), otic vesicle (ov), tectum (tct) and the tegmentum (tgm).

Expression Data

Gene:	pdlim2
Fish:	WT
Anatomical Terms:	aortic arch central nervous system gut intestine lens liver medial rectus myotome optic tectum otic vesicle pharyngeal arch 3-7 skeleton tegmentum whole organism
Stage Range:	2-cell to Day 4

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 7(3), Te Velthuis, A.J., Ott, E.B., Marques, I.J., and Bagowski, C.P., Gene expression patterns of the ALP family during zebrafish development, 297-305, Copyright (2007) with permission from Elsevier. Full text @ Gene Expr. Patterns
