FIGURE

Fig. 3

ID

ZDB-FIG-070308-2

Publication

Te Velthuis et al., 2007 - Gene expression patterns of the ALP family during zebrafish development

Other Figures

(all 7)

All Figure Page

Back to All Figure Page

Fig. 3

Expression pattern of the zebrafish-specific alp-like gene. Similar to the alp gene alp-like expression was detected by in situ hybridization at the eight different developmental stages indicated. Specific expression was found in: arterial arches (aa), axial vasculature (av), branchial arches (ba), diencephalic ventricle (dv), epiphysis (epi), intestine (in), lens (ls), midbrain-hindbrain boundary (mhb), midcerebral vein (mcev), myotomes (myt), otic vesicle (ov), retina (ret) and the telencephalic ventricle (tv).

Expression Data

Gene:	pdlim3a
Fish:	WT
Anatomical Terms:	aortic arch brain diencephalon eye gut immature eye mandibular muscle mid cerebral vein midbrain hindbrain boundary myotome otic vesicle pharyngeal arch 3-7 skeleton telencephalic ventricle whole organism (all 14)
Stage Range:	4-cell to Day 4

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 7(3), Te Velthuis, A.J., Ott, E.B., Marques, I.J., and Bagowski, C.P., Gene expression patterns of the ALP family during zebrafish development, 297-305, Copyright (2007) with permission from Elsevier. Full text @ Gene Expr. Patterns
