Fig. 2

tortuga regulates her1 at the post-transcriptional level. Embryos were hybridized with an in situ hybridization probe that binds the third intron of her1 and thus detects nascent and/or unprocessed transcript. At the 3 somite stage, mutant embryos in a clutch derived from tor^+/- parents cannot be distinguished from wild type siblings (A). At 12 and 18 somite stages, tor mutant embryos were sorted from their wild type siblings by morphological criteria before hybridization; again, no differences in the pattern of her1 transcription in wild type and tor mutant embryos are observed (B–E). Panels are dorsal views, anterior top.

Expression Data

Gene:	her1
Fish:	WT Df(Chr16:fbxl4,coq3,pnrc2,pou3f1,rspo1,gnl2,dnali1,snip1)b644
Anatomical Term:	segmental plate
Stage Range:	1-4 somites to 14-19 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
