Fig. 4

Characterization of zebrafish rbmx-morphant phenotype. Expression of otx2 (a,d), krox20 (b,e) and pax2.1 (c,f) anti-sense riboprobes at 24 hpf (a,b,c) and 48 hpf (d,e,f) in wildtype (wt) and morphant (mo) embryos, as indicated. Arrowheads indicate aberrant expression patterns of gene markers in morphant embryos. All images except of f are lateral view with anterior to the top. f is a dorsal view with anterior to the top. Dash lines indicate the relative length of the dorsoventral axis of the developing brain.

Expression Data

Genes:	egr2b otx2b pax2a
Fish:	WT WT + MO1-rbmx
Knockdown Reagent:	MO1-rbmx
Anatomical Terms:	forebrain hindbrain midbrain midbrain hindbrain boundary
Stage Range:	Prim-5 to Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
