Fig. 6

Dorsal and ventral tissues of the zebrafish gastrula are normally patterned in sid4 morphants. (A) The normal, dorsal margin of bmp4 expression is unchanged in (B) morphants. (C) No alterations of normal chordin expression were seen in (D) morphants. The light blue staining seen in C and D is a property of the BMP Purple substrate (Roche). Animal pole views in A, B; dorsal views in C, D. Embryonic stage is indicated below each panel. In situ probe is in lower right. Ratios of embryos exhibiting the phenotype are in the upper right.

Expression Data

Genes:	bmp4 chrd
Fish:	WT + MO2-sid4
Knockdown Reagent:	MO2-sid4
Anatomical Term:	unspecified
Stage:	Shield

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 282(1), diIorio, P.J., Runko, A., Farrell, C.A., and Roy, N., Sid4: A secreted vertebrate immunoglobulin protein with roles in zebrafish embryogenesis, 55-69, Copyright (2005) with permission from Elsevier. Full text @ Dev. Biol.
