Fig. 3
- ID
- ZDB-FIG-050723-2
- Publication
- Sumanas et al., 2005 - 15-Zinc finger protein Bloody Fingers is required for zebrafish morphogenetic movements during neurulation
- Other Figures
- All Figure Page
- Back to All Figure Page
Analysis of blf expression in hematopoietic mutants at 22 hpf. (A, B) cloche (clom39) homozygous embryos have lost blf expression. (A) ∼3/4 of progeny from heterozygous clo carriers display blf expression in the ICM region (arrow) while (B) ∼1/4 of embryos have very few or none blf-expressing cells. (C, D) moonshine (montu244b) homozygous embryos defective in TIF1γ transcription factor have lost blf expression. (C) <∼3/4 of progeny from heterozygous mon carriers display blf expression in the ICM region (arrow) while (D) ∼1/4 of embryos have very few or none blf-expressing cells. (E) blf expression is not affected in the progeny from the vlad tepes (vtm651) carriers defective in the gata1 transcription factor. |
Gene: | |
---|---|
Fish: | |
Anatomical Term: | |
Stage: | 26+ somites |
Reprinted from Developmental Biology, 283(1), Sumanas, S., Zhang, B., Dai, R., and Lin, S., 15-Zinc finger protein Bloody Fingers is required for zebrafish morphogenetic movements during neurulation, 85-96, Copyright (2005) with permission from Elsevier. Full text @ Dev. Biol.
