ZFIN ID: ZDB-FIG-050314-13
Loeb-Hennard et al., 2005 - Prominent transcription of zebrafish N-myc (nmyc1) in tectal and retinal growth zones during embryonic and early larval development. Gene expression patterns : GEP   5(3):341-347 Full text @ Gene Expr. Patterns
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Anatomical Terms:
Stage: Protruding-mouth

Fig. 3 Zebrafish nmyc1 is prominently transcribed in tectal and retinal growth zones at early larval stages. Expression of nmyc1 on whole-mount embryos at 72 hpf, revealed by in situ hybridization with a digoxygenin-labelled nmyc1 antisense riboprobe (blue staining, left panels) or in combination with the M phase marker phospho-histone H3 (brown nuclei, right panels except I′) (all embryos anterior left, dorsal views in A,B, lateral views in C,D). (E–H) are frontal sections of the embryos in (C, D) at the levels indicated, (I–J) are parasagittal sections of similar embryos, with magnification of the caudal tectal border in (I′) and (J) (boxed area in I). Central nervous system expression of nmyc1 labels the circumference of the optic tectum (ot, black arrowheads), the retinal marginal zone (r, red arrowheads), the cerebellar plate (cb, green arrowheads) and rhombic lips in rhombomere 2 (rl, blue arrowheads). Note the striking coincidence between these sites and proliferating, PH3-positive cells.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
mycn WT standard conditions Protruding-mouth cerebellum ISH
Protruding-mouth optic tectum ISH
Protruding-mouth retina ISH
Protruding-mouth rhombomere 2 ISH
Antibody Labeling Details No data available
Phenotype Details No data available
Acknowledgments:
ZFIN wishes to thank the journal Gene expression patterns : GEP for permission to reproduce figures from this article. Please note that this material may be protected by copyright.

Reprinted from Gene expression patterns : GEP, 5(3), Loeb-Hennard, C., Kremmer, E., and Bally-Cuif, L., Prominent transcription of zebrafish N-myc (nmyc1) in tectal and retinal growth zones during embryonic and early larval development, 341-347, Copyright (2005) with permission from Elsevier. Full text @ Gene Expr. Patterns
